● Access mode example 4:

The search concept is in Z. S contains the column index of the column in which concept is

being searched for. The line index of the concept found is output:

VAR1 = Thread[0.125,1,4] ;VAR1 has the value 2

Explanation:

Search for value 0.125 in column 1 of array "Thread" and transfer the line index of the value

found to VAR1.

● Access mode example 5:

Z contains the line index of line in which concept is being searched for. The search concept

is in S. The column index of the concept found is output:

VAR1 = Thread[4,0.2,5,1] ;VAR1 has the value 1

Explanation:

Search in line 4 of the "Thread" array for the value 0.2 and transfer the column index of the

value found to VAR1. Comparison mode 1 was selected because the values of line 4 are

not sorted in ascending order.

7.2.3 Scanning the status of an array element

Description

The Status property can be used to run a scan to find out whether an array access operation

is supplying a valid value.

Programming

Syntax:

Identifier [Z, S, [M[,C]]]

.vld

Description: Status is a read-only property.

Parameters: Identifier Name of array

Return Value: FALSE =

TRUE =

invalid value

valid value

Example

DEF MPIT = (R///"MPIT",,"MPIT",""/wr3)

DEF PIT = (R///"PIT",,"PIT",""/wr3)

PRESS(VS1)

MPIT = 0.6

IF MET_G[MPIT,0,4,1].VLD == TRUE

PIT = MET_G[MPIT,1,0].VAL

REG[4] = PIT

REG[1] = "OK"

ELSE

REG[1] = "ERROR"

Graphic and logic elements

7.2 Defining an array

SINUMERIK Integrate Run MyScreens (BE2)

200 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
