Rounding the contour
SD55582 $SCS_TURN_CONT_TRACE_ANGLE Contour turning: Minimum angle for
rounding the contour
= 5 Specifies the angle between the cutting edge and contour, above which for contour turning,
the contour is rounded in order to remove residual material (default value).
SD 55218 $SCCS_FUNCTION_MASK_TURN_SET Turning function screen
Bit 3 Chamfer in CYCLE930 as chamfer length (CHF)
Bit 4 Retraction from internal machining (CYCLE951)
= 0 Compatibility as before
If, during the cycle, the necessity for tightening is detected at the corner, the tool is retracted
from the internal machining, otherwise it is not.
= 1 Retraction from internal machining is generally in the cutting axis.
21.5.3 Setting-up ShopTurn cycles for turning
MD52210 $MCS_FUNCTION_MASK_DISP Function screen display
Bit 0 = 1 Dimension system for programs always in the basic system (default setting)
Bit 1 = 1 Face view when turning (default setting)
Bit 4 = 1 Display follow-on tool in the T,F,S window
MD52212 $MCS_FUNCTION_MASK_TECH Cross-technology function screen
Bit 2 Approach logic for stepped drill
Bit 3 Block search cycle for ShopMill / ShopTurn
= 0 The E__ASUP or F_S_ASUP cycles are not called in the block search cycle
PROG_EVENT.SPF
= 1 The E__ASUP (under ShopMill) or F_S_ASUP (under ShopTurn) cycles are called in the
block search cycle PROG_EVENT.SPF
Bit 4 Approach logic using the cycle
Bit 5 The cycle for SERUPRO (CYCLE207) is called in the block search cycle
PROG_EVENT.SPF.
Bit 3 has no effect when bit 5 is set.
Bit 6 Work offset value WO cannot be entered
Bit 7 Identification of the end of tool lives in the program (ShopMill / ShopTurn)
Bit 8 Manual machine (ShopMill/ShopTurn)
Bit 9 Selection/deselection of the work offset using softkey
Bit 11 Deactivate position check for drilling and milling tools
MD52214 $MCS_FUNCTION_MASK_MILL Milling function screen
Bit 3 "Inner/rear" machining is enabled in the ShopTurn screens which themselves define the
machining plane.
Technologies and cycles
21.5 Turning
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 533
