Lathe with X and Z axes, main and tool spindle
For example, for a lathe with X and Z axes, main spindle (C1) and tool spindle (WZ), you can
configure the following channel-specific machine data:
MD20080 $MC_AXCONF_CHANAX_NAME_TAB[ ] Channel axis name in the channel
[0] = XC Channel axis XC
[1] = ZC Channel axis ZC
[2] = C1 Main spindle C1
[3] = WZ Tool spindle WZ
Lathe with X and Z axes, main and tool spindle and counterspindle
For example, for a lathe with X and Z axes, main spindle (C1), tool spindle (WZ) and
counterspindle (C2), you can configure the following machine data:
MD20080 $MC_AXCONF_CHANAX_NAME_TAB[ ] Channel axis name in the channel
[0] = XC Channel axis XC
[1] = ZC Channel axis ZC
[2] = C1 Main spindle C1
[3] = WZ Tool spindle WZ
[5] = C2 Counterspindle C2
Lathe with X and Z axes, main and tool spindle and Y axis
For example, for a lathe with X, Z and Y axes, main spindle (C1) and tool spindle (WZ), you
can configure the following machine data:
MD20080 $MC_AXCONF_CHANAX_NAME_TAB[ ] Channel axis name in the channel
[0] = XC Channel axis XC
[1] = ZC Channel axis ZC
[2] = C1 Main spindle C1
[3] = WZ Tool spindle WZ
[5] = YC Channel axis YC
21.5.8 Cylinder surface transformation (TRACYL)
Software option
You require the following software option in order to use this function:
"Transmit and peripheral surface transformation"
Function
Using the cylinder surface transformation function (TRACYL), you can machine the peripheral
surface of a turned part.
Technologies and cycles
21.5 Turning
SINUMERIK Operate (IM9)
544 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
