Example 2
Magazine location 1 of the buffer will be assigned to channel 1.
Magazine location 2 of the buffer will be assigned to channel 2.
<CHANNELMAGAZINEASSIGNMENT>
<CHANNELNO_1>
<MAGAZINE_9998>
<Places value="1" type="QString" />
</MAGAZINE_9998>
</CHANNELNO_1>
<CHANNELNO_2>
<MAGAZINE_9998>
<Places value="2" type="QString" />
</MAGAZINE_9998>
</CHANNELNO_2>
</CHANNELMAGAZINEASSIGNMENT>
12.2.18 Assignment between magazines and magazine locations and coordinate systems
Requirement
Turning technology or milling technology and technology extension turning have been set:
Name of the associated configuration file sltmturninglistconfig.xml or sltmmillturnlistconfig.xml.
Assignment between the magazine or magazine locations and the coordinate system
With this setting, magazines and magazine locations can be assigned to coordinate systems.
This is useful if the machine is configured in such a way that a magazine or magazine location
does not match the position of the coordinate system set in the channel. The assignment
between magazine or magazine location and coordinate system can be defined here.
As a consequence of this configuration, the tool icons are output with reference to their position
depending on the coordinate system.
This setting option is only available in turning technology and in milling technology with the
technology extension milling.
<COORDSYSMAGAZINEASSIGNMENT> tag
In tag <COORDSYSMAGAZINEASSIGNMENT>, you will find the entries for the assignment
between magazines or magazine locations and coordinate systems.
Entries Meaning
COORDSYSNO_XXX XXX stands for the number of the coordinate system.
Magazines Number of the magazines that are assigned to the channel.
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
214 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
