Flags acc. to the AS-i specification Description
Operating mode Operating mode state
Auto.-Addr.progr. executed Automatic address assignment executed
Auto-Addr.progr. possible Automatic address assignment possible
AS-i slave with addr.=0 available Slave with address 0 available
Reference config. = actual config. Target configuration equal to actual configuration
State Marking
Slave OK Green
Slave fault Red
Slave is available, but not configured Yellow
Procedure
1. Select the "Diagnostics" operating area.
2. Press the menu forward key twice and the "AS-i diag." softkey.
The "Diagnostics AS-Interface" window is opened.
3. Select the required DP AS-interface.
The complete diagnostics information is displayed.
The values in italics indicate an error counter > 0.
18.14 Backing up log data for service case
If system problems occur, it is necessary to back up all of the existing log files to provide them
to the hotline for diagnostics. There are two options available to you:
● Backing up log data to USB
● Backing up log data as ZIP file
18.14.1 Backing up log data to USB
Backing up all log data using a special key combination:
CTRL + ALT + D
This function generates a directory on the front USB. If a USB flash drive is available, the
directory is created on the storage medium. The directory name has the following structure:
Service and diagnostics
18.14 Backing up log data for service case
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 481
