Entries Meaning
ShowConflictPositionAndDirection Marking of a conflict; tool position and cutting direction do not
match.
True - default setting.
ShowConflictActiveToolWarning Marking of a conflict; turret magazine type and the active tool
are not at the the machining position.
True - default setting.
Example
<SETTINGS>
<ReactivateWithMagPos value="false" type="bool" />
<MagazineMoveMessage value="false" type="bool" />
<CreateNewToolDialog value="true" type="bool" />
<MagazineSelectionDialog value="false" type="bool" />
<AccessLevelWriteDetailsAllParameter value="4" type="int" />
</SETTINGS>
12.2.2 Configuring tool lists
<LISTCONFIGURATION> tag
The entries used for configuring the following list views are located in the
<LISTCONFIGURATION> tag:
● "Tool List" window, identifier <SlTmToollistForm>, see the 1st example.
● "Tool Wear" window, <SlTmToolwearForm> identifier
● "Magazine" window, <SlTmToolmagazinForm> identifier
● "Tool Data OEM" window, <SlTmTooloemForm>identifier
This window is hidden in the default configuration. The window is only displayed when you
enable it with <Enabled>, see the 3rd example.
● "Tool Selection" window, <SlTmToolselectionForm> identifier: In order to select a tool
this window can be displayed in the program input screen.
Entry Meaning
Enabled True - window is displayed.
False - window is hidden.
CAPTION Definition of the list name.
Text Used as label/item below the "CAPTION" to define the heading text.
COLUMNX Column selection: X stands for the column number.
TOOLTYPE_ALL The column setting applies to all tool types.
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 177
