Configuring the network
17
Overview
If you wish to perform network settings in SINUMERIK Operate, you have the following options:
● The Start-up operating area allows you to set up all of the basic configurations for the plant
and company networks (see Section "Displaying the network overview (Page 371)").
● The Diagnostics operating area gives you an effective overview of all available network
adapters and allows you to assign and check settings for the company network or the DHCP
server, for example (see Section "Configuring TCP/IP diagnostics (Page 392)").
17.1 Displaying the network overview
All the available interfaces and their network settings are listed in the "Overview of the network
settings" window. For example, the IP addresses, subnet masks and MAC addresses for the
company and system network are displayed here. You have the option of editing the settings.
Procedure
1. Select the "Start-up" operating area.
2. Press the "Menu forward" key.
3. Press the "Network" softkey.
The "Overview of the Network Settings" window opens.
4. Press the "Change" softkey to edit settings.
See also
Settings of the system network (Page 372)
Settings of the factory network (Page 375)
Saving network settings (Page 377)
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 371
