FindWindow (findwindow.exe) is located in the following directory:
C:\Program Files (x86)\Siemens\MotionControl\Common\FindWindow\
Application
1. Start the PCU.
2. Install the application to be integrated using OEMFrame.
3. Open the application.
4. Open the FindWindow program.
5. Left-click to drag the red cross to the title bar of the application in the FindWindow program.
6. Check the application parameters "FileName", "ClassName", etc.
7. Select the parameters "Gimmekey", "Disablekeys", etc. via the checkboxes as needed.
If the configuration file "systemconfiguration.ini" exists and you want to expand it:
8. Copy the entries to the clipboard by clicking on "Copy to Clipboard".
9. Open the existing configuration file and insert the parameters from the clipboard. To do
this, right-click on the position at which the parameters are to be inserted and then click on
"Insert".
10. Save the modified configuration file.
- OR -
If the configuration file "systemconfiguration.ini" does not exist and you want to create it:
8. Click on the "Create systemconfiguration.ini" button.
A new configuration file is simultaneously created in the directory for FindWindow. Any
existing configuration file will be overwritten.
9. Insert a copy of the new configuration file into the provided directory.
Note
If you include a 64-bit application, no parameter data is displayed under "FileName". In this
case, an information dialog opens, which allows you to manually select the application.
Note
Only use the 8.3 Notation for filenames if problems should occur without this parameterization.
23.4 Setting text legibility by means of font smoothing
To ensure that particularly small TrueType fonts can be read more easily, the text display is
already optimized under Windows by default. The settings perform fine font smoothing of the
font and provide an improved display on the screen (Windows ClearType technology).
If you want to change the text legibility for SINUMERIK Operate, you can adjust the following
parameters via the "slstartup.ini" file.
SINUMERIK Operate on PC/PCU
23.4 Setting text legibility by means of font smoothing
SINUMERIK Operate (IM9)
676 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
