Decimal place Meaning
HUNDRED MILLION Enable data set
4 = Kinematics active (fixed value)
2)
See system variables $NT_AUX_POS[n,0] to $NT_AUX_POS[n,2]
Meaning of the bits of $NT_CNTRL[n]
You can make the following settings for the machine adaptation:
Bit 0 = 1 Fixed sequence of axes
For easier handling of the data, the sequence of the axes is fixed:
1. Rotary table
2. Swivel axis
3. Tool spindle
Bit 1 = 1 Rotary table is spindle
Bit 2 = 0 Swivel axis is not a spindle
Bit 3 = 0 Tool spindle is not a spindle (during turning)
Bit 4 = 0 1st rotary axis has no Hirth joint (rotary table)
3)
Bit 5 = 0 2nd rotary axis has no Hirth joint (swivel axis)
3)
Bit 6 = 0 3rd rotary axis has no Hirth joint (tool spindle)
3)
3)
It is not permissible that either the 2nd or the 3rd rotary axis has a Hirth joint.
21.8.3 Behavior at reset and power on
Behavior at reset
Make the following settings so that the kinematics transformation is retained after reset and
the turning tool can be used in JOG mode:
MD20110 $MC_RESET_MODE_MASK Definition of the basic control setting after reset /
part program end
Bit 7 = 1 The current setting for active transformation is retained after reset / part program end.
Bit 16 = 1 The current setting of the master spindle is retained.
MD20112 $MC_START_MODE_MASK Definition of the basic control setting after part pro‐
gram start
Bit 7 = 0 Start behavior, "active kinematics transformation"
MD20152 $MC_GCODE_RESET_MODE[ ] Reset behavior of G groups
[5] = 1 The current setting of the 6th G group is also retained after reset / part program end
(G17, ...).
Technologies and cycles
21.8 Turning on milling machines
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 605
