Identifier Parameter or property System variable
*)
MultiToolProtAreaFile File name of the multitool description which
is required to determine the protection zone
$TC_MTP_PROTA
MultiToolKindOfDist Type of distance input of the multitool loca‐
tions
$TC_MTP_KD
MultiToolKindOfDistRO Type of distance input of the multitool loca‐
tions, only read access
$TC_MTP_KD
MultiToolDistAngle Type of distance input of the multitool loca‐
tions as an angle
$TC_MTP_KD
MultiToolDistAngleRO Type of distance input of the multitool loca‐
tions as an angle, read only access
$TC_MTP_KD
MultiToolState Multitool status in the hexadecimal notation $TC_MTP8
MultiToolStateEnabled Multitool status - multitool released $TC_MTP8, Bit1
MultiToolStateLocked Multitool status - multitool locked $TC_MTP8, Bit2
MultiToolStateLockedRO Multitool status - multitool locked, only read
access
$TC_MTP8, Bit2
MultiToolStateInChange Multitool status - multitool is being changed $TC_MTP8, Bit5
MultiToolStateFixed Multitool status - multitool fixed location co‐
ded
$TC_MTP8, Bit6
MultiToolStateUsed Multitool status - multitool was in use $TC_MTP8, Bit7
MultiToolStateAutoReturn Multitool status - automatic return $TC_MTP8, Bit8
MultiToolStateIgnoreLocked Multitool status - do not observe locked sta‐
tus
$TC_MTP8, Bit9
MultiToolStateMarkedToUnload Multitool status - multitool is selected to be
unloaded
$TC_MTP8, Bit10
MultiToolStateMarkedToLoad Multitool status - multitool is selected to be
loaded
$TC_MTP8, Bit11
MultiToolStatePermanent Multitool status - multitool is a master tool $TC_MTP8, Bit12
MultiToolState1To1Exchange Multitool status - one to one replacement $TC_MTP8, Bit14
MultiToolStateHandTool Multitool status - manual tool $TC_MTP8, Bit15
MultiToolStateLockMtIfToolLock Multitool status - multitool is locked if a tool
is locked in multitool
$TC_MTP8, Bit16
MultiToolUser_1, ... MultiToolUs‐
er_10
OEM multitool parameters 1 to 10 $TC_MTPC1, ...
$TC_MTPC10
MultiToolAppl_1, ... MultiToo‐
lAppl_10
Siemens application multitool parameters
1 to 10
$TC_MTPCS1, ...
$TC_MTPCS10
*)
Parameter corresponds to the system variable or the system variable is the basis for this
parameter.
12.2.2.8 Multitool location parameter identifiers
For the multitool location parameters, the following identifiers are used in the configuration file:
Identifier Parameter or property System variable
*)
MultiToolDist Multitool location distance taking into account
the actual type of distance input of the multitool
-
MultiToolPlaceDistLength Multitool location distance, length $TC_MTPPL
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
190 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
