Machine and setting data

7.1 Machine and setting data

Overview

Prefix Number ranges Machine/setting data Storage in range

(softkey)

$MM 9000 - 9999 Display machine data Display MD

$MNS 51000 - 51299 General configuration machine data General MD

51300 - 51999 General cycle machine data

$MCS 52000 - 52299 Channel-specific configuration machine data Channel MD

52300 - 52999 Channel-specific cycle machine data

$MAS 53000 - 53299 Axis-specific configuration machine data Axis MD

53300 - 53999 Axis-specific cycle machine data

$SNS 54000 - 54299 General configuration setting data General SD

54300 - 54999 General cycle setting data

$SCS 55000 - 55299 Channel-specific configuration setting data Channel SD

55300 - 55999 Channel-specific cycle setting data

$SAS 56000 - 56299 Axis-specific configuration setting data Axis SD

56300 - 56999 Axis-specific cycle setting data

References

You can find a detailed description of the machine and setting data in the following

documentation:

Machine Data and Parameters List Manual

7.2 Displaying/editing machine data

You can access the following machine data in the "Start-up" operating area.

● General machine data ($MN) and general configuration machine data ($MNS)

● Channel-specific machine data ($MC) and channel-specific configuration machine data

($MCS)

● Axis-specific machine data ($MA) and axis-specific configuration machine data ($MAS)

● Drive-specific machine data ($M_)

● Machine data control unit: Drive parameters

● Machine data feed-in: Drive parameters
