MD24444 $MC_TRAFO_GEOAX_ASSIGN_TAB_6[ ] Assignment of geometry axes to channel
axes for transformation 6.
[0] = 1 1st axis = channel axis XC
[1] = 3 2nd axis = channel axis YC
[2] = 2 3rd axis = channel axis ZC
MD24995 $MC_TRACON_CHAIN_1[ ] Transformation linking
[0] = 1 Number of the TRANSMIT transformation (main spindle) for linking.
[1] = 5 Number of the TRAANG transformation for linking. Data set for linking (TRACON) of
cylinder surface transformation on main spindle (TRACYL) and inclined axis (TRAANG).
Data set for linking (TRACON) of cylinder surface transformation on main spindle (TRACYL)
and inclined axis (TRAANG):
MD24450 $MC_TRAFO_TYPE_7
= 8192 Type of transformation 7 in the TRACON channel.
MD24454 $MC_TRAFO_GEOAX_ASSIGN_TAB_7[ ] Assignment of geometry axes to channel
axes for transformation 7.
[0] = 1 1st axis = channel axis XC
[1] = 3 2nd axis = channel axis YC
[2] = 2 3rd axis = channel axis ZC
MD24996 $MC_TRACON_CHAIN_2[ ] Transformation linking
[0] = 3 Number of the TRACYL transformation (main spindle) for linking.
[1] = 5 Number of the TRAANG transformation for linking.
21.5.11 Spindle speed limitation for current program
Speed limits are programmed in the part program. If the part program is applied, the spindle
speed limits are entered in the setting data and saved there after the end of program.
However, if the modified speed limits must not apply after the end of the program, you can
change the property with the following commands in the GUD block of the machine
manufacturer:
Changing spindle speed limits for the current program only
REDEF $SA_SPIND_MAX_VELO_LIMS PRLOC ; maximum spindle speed limit for V
constant (G96)
REDEF $SA_SPIND_MAX_VELO_G26 PRLOC ; maximum spindle speed limit for rpm
(G26)
Technologies and cycles
21.5 Turning
SINUMERIK Operate (IM9)
554 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
