● Zoom
– Increasing or decreasing the section
● Cursors: The cursor display provides functions that allow one, two or both curves to be
precisely measured.
– Cursor A
– Cursor B
– Both cursors
– Snap to curve: The cursor precisely moves along the curve
– Point mode: Cursor jumps directly to various values.
– High point mode: The cursor jumps from one peak value to the next.
– Low point mode: Cursor jumps to the lowest values.
Requirement
The "Trace" graphic window is open and the trace has been recorded.
Editing curves
You jump from one variable to the next using the <TAB> key.
You jump back using the <Ctrl> and <TAB> keys.
With the cursor keys, you set marks, move to individual values and can
define a zoom range.
18.12.5.2 Selecting a variable
You have the option of displaying the selected variables as legend and to make a selection
using a checkbox.
Legend
Numbering the variables
Axis identifier
Comment of the variables
Service and diagnostics
18.12 Trace
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 471
