Display Meaning/information
Communication state Actual communication state of the slot
If a value is not available for the NC axes, then the display remains hidden.
Green: Slot used by the NC, communication active
Red: Slot used by the NC, communication currently not active
Gray: No NC axis
Machine axis Display of the name defined in the machine data for this slot
If the slot is not assigned to any NC axis, then the display remains hidden.
Telegr. type (NC) Displays the assigned telegram type
If a telegram type is not assigned in the NC machine data, then the display
remains hidden.
Procedure
1. Select the "Diagnostics" operating area.
2. Press the "Menu forward" key and the "Bus TCP/IP" softkey.
The "PROFIBUS Diagnostics" window is opened.
3. Select the PROFIBUS configuration for which you want to display details.
4. Press the "Details" softkey.
The "PROFIBUS Diagnostics ... - Details" window is opened.
18.10 Drive system
18.10.1 Displaying drive states
Status display
The "Drive System Diagnostics" window displays the status information about the drive units
and the associated drive objects. The status symbols have the following meaning:
Display icon Meaning
Green The drive object is in (cyclic) operation, without any detected
problems.
Yellow The drive object has detected a less serious problem, i.e. a
warning is pending, for example, or enables are missing.
Red This drive object has detected a serious problem, for example,
an alarm is pending.
Service and diagnostics
18.10 Drive system
SINUMERIK Operate (IM9)
450 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
