PLC bit: -1
Activation: Activated
5. Press the "OK" softkey to save the values.
Cylinder element under tool holder
1. Mark the "Tool holder" machine protection area and press the "New ele‐
ment" softkey.
2. Select the "Cylinder" protection area element and press the "OK" softkey.
3. Enter the following values:
Name: SBE tool holder
Color: From protection area
Detail level: From protection area
Application: Display and monitoring
Height (Z): 50
Radius: 60
Offset (X): 0
Offset (Y): 0
Offset (Z): 25
4. Press the "OK" softkey to save the values.
14.8.2.3 Creating a tool protection area
Tool under linear axis Z
1. Mark the "Z axis" kinematic element and press the "New element" softkey.
2. Press the "Collision element" softkey.
3. In the selection box, select "Tool protection area" collision element and
press the "OK" softkey.
4. Enter the following values:
Name: T
Color: red
Detail level: 0
PLC bit: -1
Activation: Activated
TO unit: 1
Magazine: 9998.
Collision avoidance
14.8 Collision avoidance example
SINUMERIK Operate (IM9)
328 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
