SD54648 $SNS_MEA_TPW_TYPE[k] Probe version
= 0 Compatibility (measuring cycles: cube, turning surface shows probe, milling surface
shows disk)
= 3 Cube
Additional settings
● Set the current zero point in the center point of the turning tool, e.g. via a settable zero
offset.
● Change the tool before the "Align turning tool" cycle call.
● Program the tool in the part program for the simulation.
Note
No tool is active after the start of the simulation.
● After the "Align turning tool" cycle call, traverse the tool to Y = 0.
● Limit the maximum speed of the tool spindle, e.g. with the tool change cycle, in order to
avoid too high a speed of the turning tool.
● The turning tools in the tool management are automatically set up by the system. You can
make your own modifications in file sltmmillturnlistconfig.xml, for example, for the OEM tool
list.
21.8.2 Setting up a kinematics transformation
In order to be able to use the turning on milling machines technology, at least one kinematics
transformation must be set up for turning.
Requirement
A kinematic chain is already available for the machine.
For further information on kinematic chaining, see Chapter "Kinematic elements (Page 299)".
Setting up parameters
Set the following machine data to set up the kinematics transformation technology:
MD18866 $MN_MM_NUM_KIN_TRAFOS Maximum number of NC transformation objects
≥ 1 This machine data specifies the maximum number of NC transformations that can be
defined with kinematic chains (variable).
Technologies and cycles
21.8 Turning on milling machines
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 603
