NetLinx Programming
128
TPI-PRO-DVI - Instruction Manual
Programming - Button Properties
The following sections describe various button properties, which are set within the TPDesign4 Touch Panel Design program.
TPDesign4 is available to download from www.amx.com. Refer to the TPDesign4 online help for detailed instructions on setting
button.
Text Formatting Codes for Bargraphs/Joysticks
Text formatting codes for bargraphs provide a mechanism to allow a portion of a bargraph’s text to be dynamically provided
information about the current status of the level (multi-state and traditional). These codes would be entered into the text field
along with any other text. The following is a code list used for bargraphs:
By changing the text on a button (via a VT command) you can modify the codes on a button. When one of the Text Formatting
Codes is encountered by the firmware it is replaced with the correct value. These values are derived from the following operations:
Given a current raw level value of 532, a range low value of 500 and a high range value of 600 the following text formatting codes
would yield the following strings as shown in the table below:
Tex t Area Inpu t Masking
Text Area Input Masking can be used to limit the allowed/correct characters that are entered into a text area. For example, in
working with a zip code, a user could limit the entry to a max length of only 5 characters but, with input masking, you could limit
them to 5 mandatory numerical digits and 4 optional numerical digits. A possible use for this feature is to enter information into
form fields. The purpose of this feature is to:
Bargraph Text Code Inputs
Code Bargraph Multi-State Bargraph
$P Display the current percentage of the bargraph (derived from
the Adjusted Level Value as it falls between the Range Values)
Display the current percentage of the bargraph (derived from the
Adjusted Level Value as it falls between the Range Values)
$V Raw Level Value Raw Level Value
$L Range Low Value Range Low Value
$H Range High Value Range High Value
$S N/A Current State
$A Adjusted Level Value (Range Low Value subtracted from the Raw
Level Value)
Adjusted Level Value (Range Low Value subtracted from the Raw
Level Value)
$R Low Range subtracted from the High Range Low Range subtracted from the High Range
$$ Dollar sign Dollar sign
Formatting Code Operations
Code Operation
$P (Current Value - Range Low Value / Range High Value - Range Low Value) x 100
$V Current Level Value
$L Range Low Value
$H Range High Value
$S Current State (if regular bargraph then resolves to nothing)
$A Current Value - Range Low Value
$R Range High Value - Range Low Value
Example
Format Display
$P% 32%
$A out of $R 32 out of 100
$A of 0 - $R 32 of 0 - 100
$V of $L - $H 532 of 500 - 600
• Force you to use correct type of characters (i.e. numbers vs. characters)
• Limit the number of characters in a text area
• Suggest proper format with fixed characters
•Right to Left
• Required or Optional
• Change/Force a Case
• Create multiple logical fields
• Specify range of characters/number for each field
