TPI Configuration Pages
56
TPI-PRO-DVI - Instruction Manual
Setup - Project Information Page
Press the Information button on the Setup Page (see FIG. 56 on page 54) to access the Project Information Page (FIG. 58).
The Project Information page displays various properties of the TPDesign4 project file currently loaded on the TPI (read-only). The
items on this page reflect the items on the Project Information tab of the Project Properties dialog in TPDesign4:
FIG. 58
Setup - Project Information Page
Setup - Project Information Page
• Back: Saves the changes and returns to the previously active touch panel page.
Note: This option is included on all Setup pages for convenience.
• Connection
Status icon:
This visual display of the connection status allows the user to have a current update of the TPI’s connection status
regardless of what page is currently active.
• A Lock only appears on the icon if the TPI has established a connection with a currently secured target Master
(requiring a username and password).
Note: This option is included on all Setup pages for convenience.
• File Name: Displays the name of the TPDesign4 project file downloaded to the TPI.
• Designer ID: Displays the designer information.
• File Revision: Displays the revision number of the file.
• Dealer ID: Displays the dealer ID number (unique to every dealer and entered in TPD4).
• Job Name: Displays the job name.
• Sales Order: Displays the sales order information.
• Purchase Order: Displays the purchase order information.
• Build Number: Displays the build number information of the TPD4 software used to create the project file.
• Creation Date: Displays the project creation date.
• Revision Date: Displays the last revision date for the project.
• Last Save Date: Displays the last date the project was saved.
• Blink Rate: Displays the feedback blink rate (10th of second).
• Job Comments: Displays any comments associated to the job. These comments are taken from the TPD4 project file.
