Cable Details and Pinout Information
22
TPI-PRO-DVI - Instruction Manual
DVI-A Male to S-Video Male Cable
NOTE: This cable corresponds to the CC-DVI-SVID DVI-to-S-Video adapter cable (FG10-2170-10), available from AMX.
Cable to be composed of:
Two 75ohm 28 AWG mini-coax cables for the Luminance (Y) and Chrominance (C) signals and returns
EMI shield metal can on DVI connector
DVI-to-S-Video Cable Pinout Information
DVI-to-S-Video Cable Pinout Information
DVI-A
Connector Pin
Signal Name Signal Name
S-Video
Connector Pin
Notes:
1 TMDS DATA 2 N Pin populated in DVI-A connector, but not connected
for this cable
2 TMDS DATA 2 P Pin populated in DVI-A connector, but not connected
for this cable
3 TMDS SHIELD 2/4 Pin not populated in DVI-A connector
4 TMDS DATA 4 N Pin not populated in DVI-A connector
5 TMDS DATA 4 P Pin not populated in DVI-A connector
6 DDC CLOCK Pin populated in DVI-A connector, but not connected
for this cable
7 DDC DATA Pin populated in DVI-A connector, but not connected
for this cable
8 ANALOG
VERTICAL SYNC
Pin populated in DVI-A connector, but not connected
for this cable
9 TMDS DATA 1 N Pin not populated in DVI-A connector
10 TMDS DATA 1 P Pin not populated in DVI-A connector
11 TMDS SHIELD 1/3 Pin not populated in DVI-A connector
12 TMDS DATA 3 N Pin not populated in DVI-A connector
13 TMDS DATA 3 P Pin not populated in DVI-A connector
14 +5VDC Pin populated in DVI-A connector, but not connected
for this cable
15 GROUND Pin populated in DVI-A connector, but not connected
for this cable
16 HOT PLUG DETECT Pin populated in DVI-A connector, but not connected
for this cable
17 TMDS DATA 0 N Pin populated in DVI-A connector, but not connected
for this cable
18 TMDS DATA 0 P Pin populated in DVI-A connector, but not connected
for this cable
19 TMDS SHIELD 0/5 Pin not populated in DVI-A connector
20 TMDS DATA 5 N Pin not populated in DVI-A connector
21 TMDS DATA 5 P Pin not populated in DVI-A connector
22 TMDS CLOCK SHIELD Pin not populated in DVI-A connector
23 TMDS CLOCK P Pin populated in DVI-A connector, but not connected
for this cable
24 TMDS CLOCK N Pin populated in DVI-A connector, but not connected
for this cable
C1 C1 ANALOG RED Pin populated in DVI-A connector, but not connected
for this cable
C2 C2 ANALOG GREEN Luminance (Y) Signal
(center conductor)
3
C3 C3 ANALOG BLUE Chrominance (C) Signal
(center conductor)
4
C4 C4 ANALOG HSYNC Pin populated in DVI-A connector, but not connected
for this cable
C5 C5 ANALOG GROUND Y, C Returns (shields) 1, 2
BACKSHELL SHIELD Pin populated in DVI-A connector, but not connected
for this cable
