Ventilation
Principle
The ventilation system provides individual ranges
of adjustment for direct or indirect ventilation to
optimise the movement of air inside the vehicle.
General
Open the air vents and position them in a way
that ensures effective climate control.
The air flow heats or cools noticeably, depending
on the set temperature.
Ventilation at front
▷ Lever for changing the air flow direction, ar‐
rows 1.
▷ Knurled wheel for the variable adjustment of
the air flow on the vents, arrows 2.
Ventilation in rear passenger
compartment
▷ Lever for changing the air flow direction, ar‐
rows 1.
▷ Knurled wheel for steplessly opening and
closing the air vents, arrows 2.
Adjusting the ventilation
Depending on the set ventilation, align the air
flow directly or indirectly toward the passengers.
Air quality
General
The air quality in the interior is improved by the
following components:
▷ Emissions-tested interior.
▷ Interior filter.
▷ Climate control system for regulating temper‐
ature, amount of air and air recirculation func‐
tion.
▷ Pre-conditioning.
▷ Automatic air recirculation control.
Interior filter
Depending on the equipment, the interior filter
cleans the inflowing outside air and improves the
air quality:
▷ Dust and pollen are filtered out from the in‐
flowing outside air.
▷ Nano-particle emissions are reduced.
Seite 289
Air conditioning
CONTROLS
289
Online Edition for Part no. 01405A38CB9 - VI/21
