5.4 Display and key adjustment functions
5-23
Functions and
Operations
* If another key is pressed during display of "Monitor/Setting item",
the following will take place:
• If the mode or level key is pressed, the first parameter in RUN
level will appear.
• If a function key set as a channel key is pressed, the channel
will change and the first parameter in RUN level of the new
channel will appear.
• If the other function key is pressed and it is also set to "Monitor/
Setting item", the "Monitor/Setting item" of that key will appear.
• If the other function key is pressed and it is set to a function
other than the above (such as the A key), that function will
activate.
* Display 3 operates as follows during Monitor/Setting item
• If PV/SP/Bank No. is displayed, Display 3 shows the bank
number.
• If PV/SP/MV is displayed, Display 3 becomes a monitor that
shows the MV.
• In cases other than the above, the display goes off.
■ Other display and key adjustment functions
Other display and key adjustment functions are available. These
functions are explained in "Section 8 Setting data".
• "PV/SP" display screen selection : Display adjustment level
• Bar graph display item (E5AR only) : Display adjustment level
• Display auto reset : Display adjustment level
• Display refresh period : Display adjustment level
• Monitor item level setting : Display adjustment level
• Display digits after PV decimal point : Initial setting level
