6.7 Operation commands (Communication/CompoWay/F)
6-11
Communication
(CompoWay/F)
6.7 Operation commands (Communication/CompoWay/F)
Operation commands are sent using the following FINS-mini command text format.
FINS-mini command text
Operation commands for the E5AR/ER are shown in the following.
*1: Operates for all channels.
*2: Specify for each channel
0: CH1, 1: CH2, 2: CH3, 3: CH4, F: All channels
*: A software reset will not respond (no service PDU response).
*: When all channels are specified, only enabled channels will respond and processing will begin from
Channel 1. If an error is detected on any one channel, an "Operation error" will result. If all channels end
normally, "Normal end" results.
Data name Explanation
MRC/SRC Specify the FINS-mini operation command.
Operation code Specify an operation code.
Related information Specify information related to the command.
Command
"30" "05"
Instruction
code
Related
information
SRCMRC
2222
Operation
code
Description
Related information
Higher Byte Lower Byte
00 Write via
communication
0
*1
0: OFF (Disabled)
1: ON (Enabled)
01 Run/Stop
0 to 3, F
*2
0: Run 1: Stop
02 Bank change
0 to 3, F
*2
0 to 7: Bank 0 to 7
03 AT run
0 to 3, F
*2
0: Currently selected PID Set No.
1 to 8: PID Set No.
04 Write mode
0
*1
0: Backup mode
1: RAM write mode
05 RAM data save
0
*1
0
06 Software reset
0
*1
0
07 Move to setting area 1
0
*1
0
08 Move to protect level
0
*1
0
09 Auto / Manual
0 to 3, F
*2
0: Auto mode
1: Manual mode
0A AT stop
0 to 3, F
*2
0: Stop
0B Initialize settings
0
*1
0
0C Cancel latch
0 to 3, F
*2
0
0D SP mode
0 to 3, F
*2
0: LSP
1: RSP
When cascade control is selected for the control mode, specify channel 2 commands for
the following operation commands:
• Run/Stop
• Auto / Manual
• SP mode
Cascade open / closed
Important
