Appendix
A-6
Appendix
Setting list
The setting list shows addresses for CompoWay/F communication and Modbus communication. Refer to
the addresses of the protocol that you are using.
The hexadecimal values in the Setting (monitor) value column are the setting ranges in CompoWay/F and
Modbus, and the values in parentheses ( ) are the actual setting ranges.
The monitor and setting values can be specified for each channel, and addresses include a channel
identifier. The addresses in the variable area map are for channel 1. To specify addresses of other
channels on a multi-point input type, refer to the table below.
Channel
Address
CompoWay/F ModBus
1 Address in setting list in Appendix Address in setting list in Appendix
2 Address in setting list in Appendix + 0100 Address in setting list in Appendix + 4000
3 Address in setting list in Appendix + 0200 Address in setting list in Appendix + 8000
4 Address in setting list in Appendix + 0300 Address in setting list in Appendix + C000
