6.9 Commands and responses (Communication/CompoWay/F)
6-29
Communication
(CompoWay/F)
Response codes: The above indicates a normal end. For the response
codes, see "6.7 Operation commands (Communication/CompoWay/
F)" (P.6-11).
■ Read machine attributes
This command reads the E5AR/ER model and communication buffer
size.
The command can be used in any state of the E5AR/ER.
Response codes: The above indicates a normal end. For the response
codes, see"6.7 Operation commands (Communication/CompoWay/F)"
(P.6-11).
Model
Size
Constant / program
Standard / Position proportional
Response
"30" "05" "0000"
Response code
SRCMRC
Symbol Size
A A size (96 × 96 mm)
E E size (96 × 48 mm)
Symbol Constant / program
(Blank) Constant
Symbol
Standard / position
proportional
(Blank) Standard
P Position proportional
Command
"05" "03"
SRCMRC
Response
"05" "03" "0000" "00D9"
Buffer sizeFormat
Response code
SRC
MRC
56789
34012
R-E
∗Bytes 7 to 9 are blank
5
