6.9 Commands and responses (Communication/CompoWay/F)
6-31
Communication
(CompoWay/F)
■ Echo back test
This command is used to perform an echo back test.
The command can be used in any state of the E5AR/ER.
Keep the test data within the following ranges depending on the
communication data length.
Response codes: The above indicates a normal end. For the response
codes, see "6.7 Operation commands (Communication/CompoWay/
F)" (P.6-11).
Communication
data length
Description
7 bits ASCII code H'20 to H'7E
8 bits ASCII code H'20 to H'7E or H'A1 to H'FE
Command
"08" "01" 0 to 200 bytes
SRC
Test data
MRC
Response
"08" "01" "0000" 0 ~ 200 bytes
SRC
Test dataResponse code
MRC
