6.6 Writing to the variable area
Write to the data area by setting the required data in the following FINS-mini command text format.
FINS-mini command text
FINS-mini response text
Response codes
Data name Explanation
MRC/SRC
Specifies the FINS-mini monitor value/setting data
write command.
Variable type Specify a variable type.
First address of write Specify the address for the beginning of the write.
Bit position Not used on the E5AR/ER. Specify "00".
Number of elements
Specifies the number of variables to be written
(max. of 25 (H'19)). Not needed for a compound
write.
Write data Enter data to be written.
Data name Explanation
MRC/SRC FINS-mini command text appears here.
Response code Result of execution of the command.
Response
code
Error name Explanation
"1002"
Command length
too short
The command is too short.
"1101" Area type error Incorrect variable type.
"1003"
Number of ele-
ments / Data num-
ber do not agree
The specified number of elements does
not agree with the actual number of data
elements.
"1100" Parameter error
Bit position specification other than "00".
Written data was outside of setting range.
"2203" Operation error
Write via communication is disabled.
Write to setting area 1 was attempted
from setting area 0.
Write to setting data of protect level was
attempted from other than protect level.
AT is running.
Calibration level in progress.
Unit error, unit change, display unit error,
internal non-volatile memory error.
"0000"
Normal end
Command
"01" "02" "00"
Write data
Number of
elements
Bit position
Starting address
of write
Variable
type
SRCMRC
"0001" to "0018"
4
24222
Response
"01" "02"
Response code
(MRES/SRES)
SRCMRC
22 4
