Appendix
A-2
Appendix
Specifications
■ Unit ratings
*1 100 to 240V AC and 24 V AC/DC are on different models. Please specify when ordering.
*2 Multi-input. Switch between temperature and analog input by input type switch.
Basic insulation between power supply
− input terminals, power supply − output terminals.
*3 The voltage output for E5AR-QQ@@@WW-@@@ is 21 mA max.
Power supply voltage
*1
100 to 240 V AC 50/60 Hz 24 V DC 50/60 Hz/24 V DC
Allowed voltage variance
range
85 to 110% of rating voltage
Power consumption
E5AR: 22 VA max.
E5ER: 17 VA max.
E5AR: 15 VA/10 W max.
E5ER: 11 VA/7 W max.
Sensor input
*2
Thermocouples: K, J, T, E, L, U, N, R, S, B, W
Platinum resistance temperature input sensors: Pt100
Current input: 4 to 20 mA DC, 0 to 20 mA DC (including remote SP input)
Voltage input: 1 to 5 V DC, 0 to 5 V DC, 0 to 10 V DC (including remote SP input)
(Input impedance: 150
Ω using current input, approx. 1 MΩ using voltage input)
Control
output
Voltage (pulse)
output
12 V DC, 40 mA max.
*3
, with short-circuit protection circuit
Current output
0 to 20 mA DC/4 to 20 mA DC 500
Ω load max. (including transfer output)
(Resolution: Approx. 54000 at 0 to 20 mA DC, approx. 43000 at 4 to 20 mA DC)
Relay output
Position proportional control type (open, close)
1a 250 V AC 1 A (including inrush current) (inductive load)
Auxiliary
output
Relay output 1a 250 V AC 1 A (resistive load)
Transistor output
Maximum load voltage 30 V DC, maximum load current 50 mA
Residual voltage 1.5 V max., leakage current 0.4 mA max.
Event
input
Contact Input ON: 1 k
Ω max., OFF: 100 kΩ max.
Non-contact Input ON: Residual voltage 1.5 V max., OFF: Leakage current 0.1 mA max.
Short-circuit current: Approx. 4 mA
Remote SP input See "Sensor input"
Potentiometer input 100
Ω to 2.5 kΩ
Transfer output See "Control output"
Control method Advanced PID or ON/OFF
Setting method Digital setting by front panel keys, setting by communication
Indicator method
7-segment digital display and LED indicators
E5AR: Character height PV 12.8 mm, SV 7.7 mm, MV 7.7 mm
E5ER: Character height PV 9.5 mm, SV 7.2 mm, MV 7.2 mm
Other functions Varies by model
Ambient operating
temperature
-10 to +55°C(no condensation or ice formation) / 3 year warranty: -10 to +50°C
Ambient operating humidity Relative humidity 25 to 85%
Storage temperature -25 to +65°C (no condensation or icing)
