Section 8 Setting data
8-2
Setting data
8.1 How to use this section
● Marks used in this section
Explains the meaning and function of a setting data item.
Shows the setting range and initial setting of a setting data item.
Used for monitor values.
Explains a procedure for operating the E5AR/ER.
Indicates where a setting data item is explained and notes related
setting data items.
● Display conditions for related setting data
A setting will only appear in the display of the E5AR/ER when the
conditions of use for the setting are satisfied (conditions of use are
indicated to the right of each setting in this section). Protected settings
are not displayed regardless of the conditions of use, although they
are in effect.
In the case of settings that can be configured separately for each
channel on a multi-point input type, appears to upper left of each
of these settings in this section.
● Order of explanation of settings
Settings are explained by level.
Function
Setting
Monitor
Operation
Reference
Reference
CH
CH
AT run/stop
at l. adj
During control using advanced PID control
Setting data for each channel
Level indication
(Display 3)
Setting data name Operation conditions
Display symbol
(Display 1)
