Section 6 Communication (CompoWay/F)
6-14
Communication
(CompoWay/F)
6.9 Commands and responses (Communication/CompoWay/F)
The E5AR/ER provides a set of applied commands that make use of variable area read/write commands,
operation commands, and other services provided by the CompoWay/F communication protocol.
E5AR/ER applied commands are explained below.
■ Monitor value read (Communication/CompoWay/F)
*1 Local SP of Bank No. that is selected and running.
Vari-
able
type
Address
Monitor value
Address
Monitor value
Ch Data name Ch Data name
"C0"
"0000"
1
PV "0200"
3
PV
"0001" Status "0201" Status
"0002" Internal SP "0202" Internal SP
"0003" None "0203" None
"0004" MV monitor (heat) "0204" MV monitor (heat)
"0005" MV monitor (cooling) "0205" MV monitor (cooling)
"0100"
2
PV "0300"
4
PV
"0101" Status "0301" Status
"0102" Internal SP "0302" Internal SP
"0103" None "0303" None
"0104" MV monitor (heat) "0304" MV monitor (heat)
"0105" MV monitor (cooling) "0305" MV monitor (cooling)
"C1"
"0003"
1
SP
*1
"0203"
3
SP *1
"0004" Bank 0: Alarm value 1 "0204" Bank 0: Alarm value 1
"0005" Bank 0: Alarm value 1 upper limit "0205" Bank 0: Alarm value 1 upper limit
"0006" Bank 0: Alarm value 1 lower limit "0206" Bank 0: Alarm value 1 lower limit
"0007" Bank 0: Alarm value 2 "0207" Bank 0: Alarm value 2
"0008" Bank 0: Alarm value 2 upper limit "0208" Bank 0: Alarm value 2 upper limit
"0009" Bank 0: Alarm value 2 lower limit "0209" Bank 0: Alarm value 2 lower limit
"0103"
2
SP
*1
"0303"
4
SP *1
"0104" Bank 0: Alarm value 1 "0304" Bank 0: Alarm value 1
"0105" Bank 0: Alarm value 1 upper limit "0305" Bank 0: Alarm value 1 upper limit
"0106" Bank 0: Alarm value 1 lower limit "0306" Bank 0: Alarm value 1 lower limit
"0107" Bank 0: Alarm value 2 "0307" Bank 0: Alarm value 2
"0108" Bank 0: Alarm value 2 upper limit "0308" Bank 0: Alarm value 2 upper limit
"0109" Bank 0: Alarm value 2 lower limit "0309" Bank 0: Alarm value 2 lower limit
"C4"
"0000"
1
Version "0200"
3
Ver sion
"0001" Modification type "0201" Modification type
"0002" PV "0202" PV
"0003" Internal SP "0203" Internal SP
"0004" Bank No.monitor "0204" Bank No.monitor
"0005" PID Set No.monitor "0205" PID Set No.monitor
"0006" Status "0206" Status
"0100"
2
Version "0300"
4
Ver sion
"0101" Modification type "0301" Modification type
"0102" PV "0302" PV
"0103" Internal SP "0303" Internal SP
"0104" Bank No.monitor "0304" Bank No.monitor
"0105" PID Set No.monitor "0305" PID Set No.monitor
"0106" Status "0306" Status
Command
"01" "01" "0001""00"
Bit position Number of elementsAddress
MRC SRC
Variable
type
