Section 4 Settings Required for Basic Control
4-12
Settings Required
for Basic Control
4.5 Selecting the temperature units
When the input type is set to temperature input (input from a thermocouple or a platinum resistance
temperature input sensor), "°C" or "°F" can be selected for the temperature units.
When using a multi-point input type, set the temperature units separately for each input (2 to 4) as appro-
priate for the number of inputs.
Selecting "°C"
1. Hold the L key down for at least 3 seconds to move from "RUN level" to
"Input initial setting level".
2. Press the M key to select "i1du: Input 1 Temperature units".
Select "°C"/"°F" with the UD key.
c: °C f: °F
3. Hold the L key down for at least 1 second to return to "RUN level".
25.0
0.0
0.0
i1-t
2
l.0
i1du
c
l.0
25.0
0.0
0.0
