Omron E5AR - MANUAL 2 User Manual

Section 6 Communication (CompoWay/F)
6-30
Communication
(CompoWay/F)
■ Controller status read (Communication/CompoWay/F)
This command reads the operation status of the E5AR/ER.
The command can be used in any state of the E5AR/ER.
Response codes: The above indicates a normal end. For the response
codes, see "6.7 Operation commands (Communication/CompoWay/
F)" (P.6-11).
◆ Operation state
The operation state of each channel is indicated using a 2-bit code.
◆ Related information
* OR of channels set in "Number of enabled channels".
* When the channel does not exist, is "Not occurred: 0".
* If this command is used in setting area 1, the related information is
undefined.
Command
"06" "01"
SRCMRC
Response
"06" "01" "0000"
Related information
Operation
state
MRC SRC Response code
Bit position Operation state
00 Operating
01
Error
(MV at PV error output)
10
Stopped
(Including setting area 1)
11 Manual mode
7
ch4 ch3 ch2 ch1
6543210
0000
Bit position
Bit position Status
Bit description
0 1
0Blank −−
1Blank −−
2 CT input error Not occurred Occurred
3 RSP input error Not occurred Occurred
4 Potentiometer error Not occurred Occurred
5 Exceeds display range Not occurred Occurred
6 Input error Not occurred Occurred
7Blank −−
76543210Bit position
