Section 6 Communication (CompoWay/F)
6-6
Communication
(CompoWay/F)
6.3 FINS-mini text
The FINS-mini command text and FINS-mini response text form the body of command/response commu-
nication.
FINS-mini command text and FINS-mini response text are configured
as follows.
Command text FINS-mini command text consists of an MRC (main request code) and
an SRC (sub request code), followed by the required data.
Response text FINS-mini response text consists of the MRC and SRC, followed by an
MRES (main response code) and SRES (sub response code), and
then the required data.
If the specified FINS-mini command was not successfully executed,
the response will only contain the MRC, SRC, MRES and SRES.
List of FINS-mini service commands (communication/CompoWay/F)
02H "00" "0" 03H
FINS-mini
command text
SID
Sub-address
Node No.STX
SRC
2 bytes
Data
ETX BCC
MRC
2
02H "00" 03H
FINS-mini
Response textEnd code
Sub-address
Node No.STX
SRES
2 bytes
Data
ETX BCC
MRC
2
SRC
2
MRES
2
MRC SRC Service name Description
"01" "01" Monitor value / setting data read Reads monitor values / setting data.
"01" "02" Monitor value / setting data write Writes monitor values / setting data.
"01" "04" Monitor value / setting data compound read
Performs multiple reads of monitor values / set-
ting data.
"01" "13" Monitor value / setting data compound write
Performs multiple writes of monitor values / set-
ting data.
"01" "10"
Monitor value / setting data compound
stored read
Sequentially reads contents of addresses spec-
ified in "monitor value / setting data compound
read store".
"01" "11"
Monitor value / setting data compound read
store (write)
Specifies addresses to be read using "monitor
value / setting data compound stored read".
"01" "12"
Monitor value / setting data compound read
store check (read)
Reads the contents stored using "variable area
compound read store".
"05" "03" Machine attribute read Reads the model and other attributes.
"06" "01" Controller status read Reads the operation status.
"08" "01" Echo-back test Performs an echo-back test.
"30" "05" Operation command
Commands such as Run/Stop, AT Execute /
Cancel, and "Move to setting area 1".
