Appendix
A-4
Appendix
Sensor input setting ranges · Indicator (control) ranges
• Applicable input type standards are as follows:
K, J, T, E, N, R, S, B : JIS C1602-1995
L : Fe-CuNi, DIN43710-1985
U : Cu-CuNi, DIN43710-1985
W : W5Re/W26Re, ASTM E988-1990
Pt100 : JIS C1604-1997, ICE751
Input type
Specifica-
tion
Setting
value
Input setting range Display (control) range
°C °F °C °F
Platinum
resistance
temperature
sensor
Pt100 0 -200.0 to 850.0 -300.0 to 1500.0 -305.0 to 955.0
-480.0.0 to 1680.0
Pt100 1 -150.00 to 150.00 -199.99 to 300.00 -180.00 to 180.00 -249.99 to 350.00
Thermocou-
ple
K 2 -200.0 to 1300.0 -300.0 to 2300.0 -350.0 to 1450.0 -560.0 to 2560.0
K 3 -20.0 to 500.0 0.0 to 900.0 -72.0 to 552.0 -90.0 to 990.0
J 4 -100.0 to 850.0 -100.0 to 1500.0 -195.0 to 945.0 -260.0 to 1660.0
J 5 -20.0 to 400.0 0.0 to 750.0 -62.0 to 442.0 -75.0 to 825.0
T 6 -200.0 to 400.0 -300.0 to 700.0 -260.0 to 460.0 -400.0 to 800.0
E 7 0.0 to 600.0 0.0 to 1100.0 -60.0 to 660.0 -110.0 to 1210.0
L 8 -100.0 to 850.0 -100.0 to 1500.0 -195.0 to 945.0 -260.0 to 1660.0
U 9 -200.0 to 400.0 -300.0 to 700.0 -260.0 to 460.0 -400.0 to 800.0
N 10 -200.0 to 1300.0 -300.0 to 2300.0 -350.0 to 1450.0 -560.0 to 2560.0
R 11 0.0 to 1700.0 0.0 to 3000.0 -170.0 to 1870.0 -300.0 to 3300.0
S 12 0.0 to 1700.0 0.0 to 3000.0 -170.0 to 1870.0 -300.0 to 3300.0
B 13 100.0 to 1800.0 300.0 to 3200.0 -70.0 to 1970.0 -10.0 to 3490.0
W 14 0.0 to 2300.0 0.0 to 4100.0 -230.0 to 2530.0 -410.0 to 4510.0
Analog
input
4 to 20 mA
0 to 20 mA
1 to 5 V
0 to 5 V
0 to 10 V
15
16
17
18
19
One of following ranges depending on
scaling:
-19999 to 99999
-1999.9 to 9999.9
-199.99 to 999.99
-19.999 to 99.999
-1.9999 to 9.9999
-10 to 110% of setting range
Maximum range: -19999 to 99999
