Omron E5AR - MANUAL 2 User Manual

Section 7 Communication (Modbus)
7-26
Communication
(Modbus)
■ Move to setting area 1
Use this command to move to setting area 1.
The command is used in setting area 0. Nothing happens if the
command is used in setting area 1.
If the command is used when "Initial setting level protect" is set to "2
(Disable move to input initial setting level)", an operation error will
result.
To use this command, "Write via communication" must be enabled
using the "Write via communication" operation command.
The above indicates a normal end. For information on error responses,
see "7.7 Operation commands (Communication/Modbus)" (P.7-14).
■ Move to protect level
Use this command to move to protect level. Protect level is explained
in "4.1 Setting levels and key operation" (P.4-2).
This command is used in setting area 0. If used in setting area 1, an
operation error will result.
To use this command, "Write via communication" must be enabled
using the "Write via communication" operation command.
The above indicates a normal end. For information on error responses,
see "7.7 Operation commands (Communication/Modbus)" (P.7-14).
Command
H’06 H’00 H’00 H’07 H’00
Slave
address
Function
mode
Write start
address
Instruction
code
Related
information
CRC-16
2 2 bytes211
Response
H’06 H’00 H’00 H’07 H’00
Slave
address
Function
mode
Write start
address
Instruction
code
Related
information
CRC-16
2 2 bytes211
Command
H’06 H’00 H’00 H’08 H’00
Slave
address
Function
mode
Write start
address
Instruction
code
Related
information
CRC-16
2 2 bytes211
Response
H’06 H’00 H’00 H’08 H’00
Slave
address
Function
mode
Write start
address
Instruction
code
Related
information
CRC-16
2 2 bytes211
