3.5 Ratio control of dyeing machines
3-21
Typical Control
Examples
■ Adjustment
To adjust the PID constants, run AT.
For more information, see"4.10 Determining the PID constants (AT,
manual settings)" (P.4-20).
To change the proportion, change "Proportion setting (AP1)".
On the E5AR/ER, use normalized numbers for approxi-
mation settings such as broken-line and straight-line
approximation.
For example, use 0.200 for 20%. Also, if input 1 is K-200.0
to 1300.0°C, use 0% (0.000) for -200.0°C and 100%
(1.000) for 1300.0°C.
