■ Monitor value / setting data compound read
(Communication/CompoWay/F)
Multiple monitor values or setting data can be read by sending a single
command. Up to 20 items can be read even if the addresses are not
contiguous.
To specify the variable type or address, see "Appendix Setting list"
(P.A-6). The upper limit of an address will vary depending on the
variable type.
This command can be used in both setting area 0 and setting area 1.
If an area type error or a setting data error occurs in any of the data
being read, no data will be read.
Response codes: The above indicates a normal end. For the response
codes, see "6.5 Reading the variable area" (P.6-9).
Variable
type
Address
Setting data
Ch Explanation
"C4"
"0000" 1
Monitor values
"0100" 2
"0200" 3
"0300" 4
"C5" to "CB"
"0000" to "007F" 1
Setting data of setting area 0
"0100" to "017F" 2
"0200" to "027F" 3
"0300" to "037F" 4
"CC" to "D3"
"0000" to "0039" 1
Setting data of setting area 1
"0100" to "0139" 2
"0200" to "0239" 3
"0300" to "0339" 4
Command
"01" "04" "00"
Bit position Address
MRC SRC
Variable
type
"00"
Bit position
Address
Variable
type
"00"
Bit position
AddressVariable type
Response
"01" "04" "0000"
Type
Monitor value / Setting data
MRC SRC Response code Variable type Data
Type Monitor value / Setting data
Variable type Data
