Siemens Acuson S3000 User Manual

6 Transesophageal Transducer
Instructions for Use 6 - 39
V7M Transducer Technical Description
Transducer Type: Phased Array, multiplane
Elements: 48
Range of Array Rotation
Angle:
-12° to 192°
Distal Tip Articulation:
120° anterior, 90° posterior
Minimum Patient Weight:
3.5 kg (7.7 lbs) and above
Maximum insertion length: 700 mm
Maximum insertion width:
10.7 mm
2D-mode Transmit
Frequencies:
4.0 MHz, 5.0 MHz, 6.0 MHz, 7.0 MHz, 8.0 MHz
Color mode Transmit
Frequencies, including
CDV, Color DTI:
3.5 MHz, 3.75 MHz, 4.0 MHz, 4.75 MHz
Doppler Transmit
Frequencies, including PW,
SCW, Aux CW,
Pulsed Wave DTI:
3.5 MHz, 3.75 MHz, 4.0 MHz
Imaging Modes:
2D-mode, PW Doppler, Steerable CW Doppler, Color mode, Color DTI,
Pulsed Wave DTI, M-mode, Anatomical M-mode
Maximum Image
Field of View: 90°
Image: Sector
Operating Environment
Temperature:
Relative Humidity:
0°C to +45°C
10% to 95%
Storage Environment
Temperature:
Relative Humidity:
-10°C to +45°C
10% to 95%
Degree of protection
against electrical shock:
V7M transducers with this label are certified as type BF (not
defibrillator proof) per IEC 60601-1 Standard for Safety of
Medical Equipment
Degree of protection
against ingress of fluid:
IPX8
