Appendix E Advanced Feature Controls
Instructions for Use E - 23
Stress Echo Screen
Toolbar Buttons
Acquire Mode
Exits the Stress Echo screen and redisplays the imaging screen. This button is available only
when acquisition of Stress Echo loops is not yet complete.
Select Mode
Enables Select Mode.
Review Mode
Enables Review Mode.
Wall Motion Scoring Mode
Enables Wall Motion Scoring Mode.
LV Mode
Enables LV Mode.
Indication
Displays the Indication dialog box.
Save Examination
Saves the Stress Echo data with all loops (all loops acquired for each view or continuous
stage).
Save Examination (only selected loops)
Saves the Stress Echo data with loops selected as "preferred" only (one representative loop
Report Preview
Displays the report for the current mode when available. Reports are available for Wall Motion
and
.
Print
Prints the report for the current mode when available. Reports are available for Wall Motion
and
.
Record/Pause
Records Stress Echo data to external media.
Maintenance
Displays the Maintenance dialog box.
Exit
Displays a dialog box to save or discard changes and then closes the Stress Echo screen and
exits the Stress Echo feature.
Toggle Play
When enabled (highlighted), plays back the loops. When disabled (not highlighted), displays
one frame for each loop.
Start of Sequence
Displays the first frame of each loop.
Step Backward
Displays the previous frame of each loop.
Step Forward
Displays the next frame of each loop.
To Next Page
