7 Specialty Transducers
Instructions for Use 7 - 3
9EVF4 Transducer
WARNING: Before attempting to use endocavity transducers, you should be trained in
ultrasonography and endocavity scanning techniques, and you should be thoroughly familiar
with the safe operation of the ultrasound imaging system.
The 9EVF4 transducer is a fourSight 4D (curved array) transducer. The 9EVF4 transducer is
designed for endovaginal imaging of the general pelvic region, such as during the early stages
of pregnancy, for detection of ectopic pregnancies, and for examination of the follicles, ovaries,
fallopian tubes, inner cavities, bladder, and uterus.
Transducer Markings
The 9EVF4 transducer is designed with an orientation indicator on the handle of the transducer.
Example of orientation indicator on transducer handle.
