Appendix E Advanced Feature Controls
E - 26 Instructions for Use
Review Mode Selections
Note: Phases are stages.
Shuffle Mode
Displays all loops that represent the selected stage.
This button is available only when the Display Selected Loops button is disabled.
Show previous page
Displays loops for the previous view in the displayed stage.
Show next page
Displays loops for the next view in the displayed stage.
Shuffle Back
Displays the previous view when that view is not deselected.
This button is available only when the
button is disabled.
Shuffle Forward
Displays the next view when that view is not deselected.
This button is available only when the Display Selected Loops button is disabled.
Comparison Mode
Activates or deactivates the display of a comparison loop from the first stage and reference
loops from another stage.
Display Selected Loops
Displays the selected phases side by side for each selected view.
This button is available only when the Shuffle Mode button is disabled.
Accept
When automatic review is enabled, saves the loop for the current stage and activates
acquisition for the next view in the stage. Sets the second to last loop as the preffered loop
and saves all loops for reference.
Reject
When automatic review is enabled, reactivates acquisition for the current view and replaces
the previously acquired views.
Zoom soft key
Enables or disables magnification of the region of an image displayed within a zoom box.
Zoom All (Available only when Zoom soft key is activated)
soft key
Enables or disables magnification of the region of all displayed images within a zoom box.
Pointer to mark the first point of the zoom box when the Zoom soft key is activated.
Pointer to mark the second point of the zoom box when the Zoom soft key is activated. If the
zoom box is complete, deactivates zoom function.
Cycles through acquired loops in forward or reverse sequence.
