Appendix E Advanced Feature Controls
E - 40 Instructions for Use
Strain/Velocity Measurement Window
Control Description
Displays curves for all points in the parametric M-mode graphs.
Delete Stored
Removes all selected points from the parametric M-mode graphs and associated curves.
Pan/Zoom Magnifies the selected curve plots to a full-screen display.
Velocity Selects the velocity curve plot for magnification.
Selects the strain curve plot for magnification.
Selects the strain rate curve plot for magnification.
3D
Displays the 3D window including the 3D rendering of information in the related parametric
M-mode graph.
Toggle Filtered/Unfiltered Plots
Adjusts the smoothing in curves on all curve plots (all windows).
Export
Saves an image or clip to a storage device, network destination, or to the computer's hard disk.
Exits the displayed window and redisplays the VVI window.
3D Window and Magnification Window
The following selections are displayed on the 3D window and the magnification window
accessed from the Strain/Velocity Measurement window.
Control Description
Exports an image or clip to an external USB-compatible storage device.
Exits the displayed window and redisplays the VVI window.
