Appendix B Control Panel and Touch Screen
Instructions for Use B - 19
Workflow Controls
Patient
Opens or closes the patient registration form.
Review
 Activates the review function to view, evaluate, measure, and annotate the results of the
current examination or a previous examination stored in the local database.
 Provides access to clinical software programs:
– syngo Arterial Health Package
– syngo Velocity Vector Imaging
– syngo Auto Left Heart
– syngo Contrast Dynamics
Report
Opens or closes a patient report.
End Exam
Activates the following functions:
 Ends the exam
 Closes the current patient study
 Closes images
 Saves a report
 Initiates any actions queued to occur at the end of an exam. For example, printing or
archiving images to a storage device.
