Appendix B Control Panel and Touch Screen
Instructions for Use B - 7
Select, Select-R
Interacts with controls in the patient browser, patient registration form, patient report, system
configuration menu, and on the image screen.
Note: Press the control once to activate the selection in the description. Double-click describes the
action of pressing the control twice in rapid succession.
Active Function Description
Imaging
 Assigns control of the trackball to an object or a tool on the image screen
when you click the object or a tool, for example, the 2D field of view.
 Selects a menu item, control, marker, or other object on the image screen.
 Displays the selected thumbnail in review in a full-screen format when you
double-click the control.
Measurements
 SELECT anchors a measurement marker and either generates the next
marker for positioning or completes the measurement.

SELECT-R activates previous measurement markers for repositioning.
Review Highlights any type of image or thumbnail on the review screen.
System freeze Plays or pauses a clip during CINE.
Patient browser
Displays the contents of the selected series object in a 4:1 display format
when you double-click the control.
Annotation
Activates the last annotation or anchors the position of the current annotation
text, body marker, or arrow.
See also: For information about the SELECT control for the eSieFusion feature, refer to Chapter 9 in
this manual.
