Siemens Acuson S3000 User Manual

Appendix F Acoustic Output Reference
F - 4 Instructions for Use
Default Displayed MI and TI Values by Transducer
(Per transducer/mode that exceeds default MI or TI value of 0.4)
Refer to the Chapter 1 and Appendix A in this manual to identify transducers compatible with
your ultrasound system.
General Imaging
Mode
B
M
PWD
SCW
Color
CWD
Transducer
MI
TI
MI
TI
MI
TI
MI
TI
MI
TI
MI
TI
4C1 1.2 - 1.4 2.2(B
2
) 0.8 3.4(B
2
) - - 1.1 0.5(S
1
) - -
6C1 HD 1.4 0.5(S
1
) 1.4 1.6(B
2
) 1.1 4.0(B
2
) - - 1.4 0.8(S
1
) - -
6C2 1.0 0.5(S
1
) 1.4 1.2(B
2
) 0.7 3.1(B
2
) - - 1.0 0.8(S
1
) - -
8C3 HD 0.6 - 0.7 - 0.7
1.4(B
2
)
0.4(S
1
)
- - 0.8 - - -
9L4 1.0 - 1.0 - 1.4 1.3(B
2
) - - 0.9 1.9(S
1
) - -
12L4 0.8 - 0.8 - 1.3
0.6(B2)
0.6(S1)
- - 0.8
0.6(B2)
0.6(S1)
- -
14L5 1.0 - 0.9 - 1.1 1.8(B
2
) - - 0.9 1.2(S
1
) - -
14L5 SP 0.8 - 0.9 - 0.6 1.0(B
2
) - - 1.3 0.8(S
1
) - -
18L6 HD 1.0 - 0.7 - 1.0 1.2(B
2
) - - 1.0 0.6(S
1
) - -
4P1 1.2 1.0(S
1
) 1.4 1.9(B
2
) 1.0 3.8(B
2
) - - 1.2 1.2(S
1
) - -
4V1
0.8
0.4(S
1
)
1.1
1.4(B
2
)
0.9
4.3(B
2
)
-
-
0.8
0.8(S
1
)
-
-
4V1c 1.4 0.9(S
1
) 1.4 1.4(B
2
) 1.0 3.7(B
2
) - - 1.4 1.1(S
1
) - -
8V3 0.6 0.5(S
1
) 1.2 0.4(B
2
) 1.4 2.5(B
2
) - - 0.7 0.9(S
1
) - -
10V4 0.8 1.0(S
1
) 1.5 0.4(B
2
) 0.6 1.9(B
2
) - - 0.8 1.2(S
1
) - -
EV-8C4
0.9
0.5(S
1
)
1.3
0.7(B
2
)
1.2
2.0(B
2
)
-
-
1.0
0.6(S
1
)
-
-
EC9-4 0.4 - 0.4 - 0.6 1.0(B
2
) - - 0.8 0.4(S
1
) - -
MC9-4 0.8 - 0.8 - 1.0
1.8(B
2
)
0.9(S
1
)
- - 0.7 - - -
7CF1 1.0 - 1.2
0.9(B
2
)
0.5(S
1
)
0.5
1.7(B
2
)
0.8(S
1
)
- - 0.9
0.5(B
2
)
0.5(S
1
)
- -
7CF2 1.1 - 1.1 0.8(B
2
) 0.5 1.8(B
2
) - - 1.2 0.5(S
1
) - -
9EVF4 0.5 - 0.5 - 0.9 1.4(B
2
) - - 0.8 - - -
CW2 - - - - - - - - - - 0.1 4.9(B
2
)
CW5
-
-
-
-
-
-
-
-
-
-
0.1
3.0(B
2
)
S
1
: Soft Tissue Thermal Index, B
2
: Bone Thermal Index, C
3
: Cranial Thermal Index
