Xerox Phaser 4500 Service Manual

3-32 Phaser 4500 Service Manual
Jam At Tray N
Paper arrives early at the Registration Sensor
Error Codes
E2-01: Feed Jam at Tray 1
E2-02: Feed Jam at Tray 2
E2-03: Feed Jam at Tray 3
E2-04: Feed Jam at Tray 4
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ 150-Sheet Feeder Assembly
■ 150-Sheet Paper Cassette
■ Registration Sensor
■ Registration Actuator
(Actuator B)
■ LVPS
■ HVPS/Engine Logic Board
■ Registration Clutch
■ Feeder 1 Chute Assembly
■ Gear Assembly Housing
■ No Paper Sensor
■ Feeder 2 Chute Assembly
■ Bottom Plate Assembly
■ Retard Roller
■ Feed Clutch Assembly
■ Turn Roller
■ Turn Roller Clutch
■ 550-Sheet Feeder Assembly
■ 550-Sheet Paper Cassette
■ “150-Sheet Feeder, 550-Sheet Feeder, Main Fan”
on page 10-22
■ “24 V Interlock, Rear Cover Switch, Main Motor, Sub
Fan, Exit Motor Assembly” on page 10-18
■ “Print Engine General Wiring Diagram” on
page 10-17
■ “Print Engine Plug/Jack Locator” on page 10-3
Troubleshooting Procedure
Steps Actions and Questions Yes No
1
Remove all jammed paper from the tray?
Does the error still occur?
Go to step 2. Go to “No Paper in
Tray 1/No Paper in
Tray 2” on
page 3-61.
2
Check the condition of the paper in the tray.
Is the paper crumpled, damaged, damp,
or out of specification?
Replace the
paper.
Go to step 3.
