Xerox Phaser 4500 Service Manual

Error Messages and Codes 3-69
Replace Maintenance Kit
Error Indication
Replace Maintenance Kit
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser Assembly
■ Fuser Assembly Harness
■ HVPS/Engine Logic Board
■ “Fuser Assembly, Power Switch” on page 10-20
■ “Print Engine General Wiring Diagram” on
page 10-17
■ “Print Engine Plug/Jack Locator” on page 10-3
Troubleshooting Procedure
Steps Actions and Questions Yes No
1
1. Install a new Fuser Assembly.
2. Reset the Fuser Life (“Resetting Fuser
Life” on page 6-10).
Does the error still occur?
Replace the
HVPS/Engine
Logic Board
(page 8-89).
Problem solved.
