Xerox Phaser 4500 Service Manual

4-18 Phaser 4500 Service Manual
Registration Sensor
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Registration Sensor
■ Registration Sensor Actuator
■ 150-Sheet Feeder Assembly
■ Tray 1 Assembly Harness
■ Chute Assembly Harness
■ HVPS/Engine Logic Board
■ LVPS
■ “150-Sheet Feeder, 550-Sheet Feeder, Main Fan”
on page 10-22
■ “Print Engine General Wiring Diagram” on
page 10-17
■ “Print Engine Plug/Jack Locator” on page 10-3
Troubleshooting Procedure
Steps Actions and Questions Yes No
1
Check the Registration Sensor Actuator for
operation and shape:
1. Remove the 150-Sheet Feeder
Assembly (page 8-18).
Does the Registration Sensor Actuator
operate smoothly?
Is the flag of the Registration Sensor
Actuator formed normally to shield the
sensor detecting point?
Go to step 2. Replace the 150-
Sheet Feeder
(page 8-18).
2
Check the Registration Sensor:
1. Re-connect J241 of the Tray 1 Assembly
Harness to the Registration Sensor (with
150-Sheet Feeder removed).
2. Enter Service Diagnostics, and from the
Sensor Tests menu select Registration
Sensor.
3. Manually actuate the Registration
Sensor.
Does the sensor operate correctly?
Replace the
HVPS/Engine
Logic Board
(page 8-89).
Go to step 3.
3
Check the power to Registration Sensor:
1. Remove the Print Cartridge.
2. Measure the voltage across P/J24-9 <=>
P/J24-10 on the HVPS/Engine Logic
Board.
Is the voltage about 3.3 VDC?
Go to step 4. Go to step 6.
