Wiring Diagrams 10-3
Print Engine Plug/Jack Locator
P/J Locator Table
P/J Coordinates Remarks
10 G-108 Connects the LVPS Harness Assembly and HVPS/Engine Logic Board
11 G-108 Connects the LVPS Harness Assembly and HVPS/Engine Logic Board
13 G-109 Connects the Laser Unit Harness and HVPS/Engine Logic Board
14 G-109 Connects the Laser Unit Harness and HVPS/Engine Logic Board
15 G-109 Connects the ANT Harness and HVPS/Engine Logic Board
16 G-110 Connects the Laser Unit Harness and HVPS/Engine Logic Board
17 G-110 Connects the Laser Unit Harness and HVPS/Engine Logic Board
18 G-110 Connects the LVPS Harness Assembly and HVPS/Engine Logic Board
20 G-110 Connects the Feeder Harness 1 and HVPS/Engine Logic Board
22 H-109 Connects the Toner Harness and HVPS/Engine Logic Board
24 H-109 Connects the Chute Harness and HVPS/Engine Logic Board
26 H-109 Connects the Low Paper Sensor and HVPS/Engine Logic Board
27 G-109 Connects the LVPS Harness Assembly and HVPS/Engine Logic Board
28 H-109 Connects the HVPS/Engine Logic Board to I/P Board
29 H-107 Connects the Exit Sensor Harness 1 and HVPS/Engine Logic Board
30 H-107 Connects the Stacker Harness and HVPS/Engine Logic Board
31 G-108 Connects the Print Cartridge Guide and HVPS/Engine Logic Board
40 U-122 3.3 VDC Output from the LVPS to the DC-DC Converter
41 U-122 Connects the LVPS Harness Assembly and LVPS
42 U-122 Connects the LVPS Harness Assembly and LVPS
43 U-122 Connects the Main Motor and LVPS
44 U-122 Connects the Rear Cover Switch and LVPS
45 U-123 Connects the 24 V Interlock and LVPS
46 U-123 Connects the Fuser Harness Assembly and LVPS
47 T-124 Connects the Fuser Harness Assembly and LVPS
48 U-124 Connects the AC Harness Assembly and LVPS
101 T-122 Connects the LVPS and Exit Motor PWBA
102 T-122 Connects the LVPS Harness Assembly and Exit Motor PWBA
103 T-122 Connects the Exit Motor Assembly and Exit Motor PWBA
110 H-107 Connects the Front Panel Harness to I/P Board
