Xerox Phaser 4500 Service Manual

8-46 Phaser 4500 Service Manual
Laser Unit Assembly
(PL8.1.1)
Caution
When removing or installing the Laser Unit Assembly, set the printer on a
smooth, level work surface such as a desk. Working on a rough or inclined
surface can result in mis-alignment of the Laser Unit Assembly.
1. Laser Unit Assembly 3. Front Tie Plate
2. Cable Clamps 4. Upper Duct
s4500-111
1
P/J131
P/J140, 160, 170
2
3
4
