Image Processor Board
When installing a new Image Processor Board in the printer, you must transfer the
following parts from the old board:
■ Memory DIMMs
■ Hard Drive (if installed)
■ NVRAM
■ Configuration Card
1. Memory (RAM) DIMM 1 and DIMM 2 6. Parallel connector
2. Flash Memory (optional) 7. Ethernet connector
3. Hard Drive (optional) 8. USB connector
4. NVRAM connector 9. Health LED
5. Configuration Card
1
3
2
6
7
8
5
4
5
9
